Products
With Rich Product Line

JDB solid lubricating inlaid bearing is on the matrix of high -power brass. A high -performance solid lubricant product inlaid with graphite or MOS2 solid lubricant. It breaks through the limitations of general bearing relying on oil membrane lubrication. During the use, the solid lubrication is lubricated with the axis through friction heat

JDB-600 copper-based fine processing bearing is a high-powered bronze bearing with oil communication oil as lubrication. This product has the traditional tin -blue copper bearing function. Because of the use of high -power brass, its hardness has doubled, so using this product in low -speed occasions can double than ordinary bronze sets.



The SF-1 oil-free lubricating bearing is a steel plate as a substrate, a sintering spherical bronze powder in the middle, a mixture of the rolling polytetrafluoroethylene (PTFE) and lead, and a rolled sliding bearing. It has the characteristics of small friction coefficients, abrasion resistance, good corrosion resistance, and no oil lubrication.

The SF-2 carbon steel base boundary is self-lubricating bearing. It uses steel plates as a substrate and sintering spherical bronze powder in the middle. It is suitable for places in low speeds under normal temperature conditions, replacing traditional copper jackets to reduce costs and extend the service life.



The JF-800 dual metal bearing is steel and copper alloy products with low charcoal steel plates and sintering CUPB10SN10 or CUSN6ZN6PB3 materials on the surface. This product is the strongest loading capacity in the double alloy bearing, the balanced bridge band and pads of heavy cars;

The FB-090 bronze roll-making shaft inheritance is used as a substrate with a special formula with high-density copper alloy bands. The surface can be rolled according to user requirements. It has the advantages of high density, large loading capacity, good wear resistance, long service life, etc., to replace traditional casting copper sleeves, which can reduce the volume of mechanical volume



FZ This product is scrolled with steel balls, with copper, aluminum -based or resin as a holding frame, and arranges in an orderly manner according to a certain angle and density. The latest grooves of the circle lock beads are used to prevent copper beads from falling off. The product has the characteristics of low friction coefficients, axial and radial sports.

In addition to production standard components, SUNNOV also develops and produces various non -standard products
